 Post subject: Rear bushings and ball joints
PostPosted: Thu Jan 15, 2009 1:13 am
Offline
Lifetime Member
Lifetime Member
User avatar

Joined: Wed Apr 05, 2006 4:21 am
Posts: 1894
Location: Gilbert, AZ
Anyone got a good source to get these from that they would recommend? Anyone know if these parts are offered at NAPA, I tried typing in the Jeep P/N for the pieces but no results were showing up. Found Mopar Parts Direct and they have the bushings at $14/ea and the UBJ at $56.89 for the one. They also have the rear LCA bushins too at $24.38 and $22.88, seems there are two different sized bushings on the rear LCA???

I guess if anyone has replaced these how long would you say it took and were any "special" tools necessary to complete the job?

Thanks for any and all assistance!!

-Scott

_________________
Had 2005 KJ Rocky Mnt. Edition (destroyed)
Had 2006 KJ Sport 4x4
Have 2007 JK 4-dr Sahara 4x4 (tow package so stock 4.10s!!)
AEV 3.5" RS Lift; Schrockworks FR bumper and Warn 9.5ti winch; Cobra 75 CB; Rigid 50" LED light bar; Adventure Trailers (AT Overland) JK Kitchen setup in the cargo area.
Southern L.O.S.T. # 236487


Top
 Profile

 Post subject:
PostPosted: Thu Jan 15, 2009 7:39 pm
Offline
LOST Newbie

Joined: Thu Jul 07, 2005 9:11 pm
Posts: 40
Location: MI
Lower control arms - need a press otherwise noting special. don't know about the upper ball joint.

_________________
Formerly know as kjcgk 7/2002, Lost #50055


Top
 Profile

 Post subject:
PostPosted: Thu Jan 15, 2009 8:08 pm
Offline
Lifetime Member
Lifetime Member

Joined: Sat Apr 01, 2006 9:38 pm
Posts: 12988
Location: Colorado Springs
It would be cheaper to buy the whole LCA's with the bushings already pressed in,will save time and money in the long run,yes I know it's for the rear.Also the tri-link ball joint is pressed in just like the front LBJ's and you need to remove the whole tri-link to do it.If you have the OEM exhaust that means it has to come off to get one bolt out.


Top
 Profile

 Post subject:
PostPosted: Thu Jan 15, 2009 9:43 pm
Offline
LOST Junkie

Joined: Sat Jul 30, 2005 7:38 pm
Posts: 786
Location: on the bayou
Scott, i think i might have my old rear LCAs laying around in the shed. I'll try to check in the morning.

Mike


Top
 Profile

 Post subject:
PostPosted: Fri Jan 16, 2009 1:01 am
Offline
Lifetime Member
Lifetime Member
User avatar

Joined: Wed Apr 05, 2006 4:21 am
Posts: 1894
Location: Gilbert, AZ
how old are they mike? I just have this horrible popping or rattling noise coming from the rear, almost sounds like it is coming from the rear passenger side but I think it is the UCA ball joint, in which case I can get a brand new one on a new UCA with new bushings too for $157+ shipping. I'll have to get under it tomorrow and check it out and verify the condition for sure of all the bushings but there is something definitely making noise back there, shocks are tight too so they are not rattling loose or anything.

_________________
Had 2005 KJ Rocky Mnt. Edition (destroyed)
Had 2006 KJ Sport 4x4
Have 2007 JK 4-dr Sahara 4x4 (tow package so stock 4.10s!!)
AEV 3.5" RS Lift; Schrockworks FR bumper and Warn 9.5ti winch; Cobra 75 CB; Rigid 50" LED light bar; Adventure Trailers (AT Overland) JK Kitchen setup in the cargo area.
Southern L.O.S.T. # 236487


Top
 Profile

 Post subject:
PostPosted: Fri Jan 16, 2009 12:35 pm
Offline
Lifetime Member
Lifetime Member

Joined: Mon Jul 11, 2005 1:03 pm
Posts: 8052
Location: Kentuckeeee
Dont need any special tools, just some sockets and wrenches. Need some big ones, I believe 21mm is the biggest, cant remember for sure though.

Taking the lower control arms off is very easy. Take two bolts for the sway bar then the two bolts out per arm and they are done.


For the upper, take the two bolts out of the frame rail and then you can either remove the three bolts(21mm i think) holding the bracket on for the ball joint or try to take the one bolt out that holds the ball joint in the diff. I took the whole axle out which made it easier to work with.






_________________
LOST KJ'S
Where are you going???
Current Jeep: 2004 Jeep Liberty
-Atlantic Blue
-Air Ride Rear Suspension ; OME/Rustys Lift ; Powertrax Locker ; Moog Lower Ball-Joints ; 245/70/16 Yokohama Geolander A/T-S's on MOABS ; Flowmaster 50 SUV
Lost #007082
http://www.cardomain.com/id/jeepjeepster


Top
 Profile

 Post subject:
PostPosted: Fri Jan 16, 2009 3:00 pm
Offline
Lifetime Member
Lifetime Member
User avatar

Joined: Wed Apr 05, 2006 4:21 am
Posts: 1894
Location: Gilbert, AZ
Unfortunately can't see the pics here at work, but thanks for the info!!

_________________
Had 2005 KJ Rocky Mnt. Edition (destroyed)
Had 2006 KJ Sport 4x4
Have 2007 JK 4-dr Sahara 4x4 (tow package so stock 4.10s!!)
AEV 3.5" RS Lift; Schrockworks FR bumper and Warn 9.5ti winch; Cobra 75 CB; Rigid 50" LED light bar; Adventure Trailers (AT Overland) JK Kitchen setup in the cargo area.
Southern L.O.S.T. # 236487


Top
 Profile

 Post subject:
PostPosted: Fri Jan 16, 2009 7:43 pm
Offline
clean machine
clean machine

Joined: Tue Oct 18, 2005 11:52 pm
Posts: 1211
Slightly off topic. Does the rear stabilizer bar act to reduce sideways pressures on the front part of the lower control arms? (bushing/bolt assembly) Do those without rear stabilizers have any extra wear on these points?


Top
 Profile

 Post subject:
PostPosted: Sat Jan 17, 2009 10:32 pm
Offline
LOST Member
User avatar

Joined: Sat Nov 29, 2008 10:36 pm
Posts: 203
snowsport wrote:
Slightly off topic. Does the rear stabilizer bar act to reduce sideways pressures on the front part of the lower control arms? (bushing/bolt assembly) Do those without rear stabilizers have any extra wear on these points?


In theory, Im sure it could slightly.. But probably not enough to be concerned about,

_________________
A Jeep and a couple Fords.


I would wreck Kate Hudson.


Top
