Quick help needed from you stereo guys.

W3CSX · **Posted:** Thu Feb 01, 2007 6:51 pm

I’m in the middle of a project and have my dash all apart. I need to know which wire on the stereo is the dimmer. I was told it's the yellow and black, but I do not have that color.

I cant drive it until get it back together. :shock:

Thanks
Jason

jinstall · **Posted:** Fri Feb 02, 2007 9:45 am

If you used a cable adapter like Metra it should be clearly marked. If you just cut the facotory harness shame on you.

1badkj · **Posted:** Fri Feb 02, 2007 12:03 pm

I could not find anything on the color on the stereo harness but I know that it is controlled by the multifunction switch which says OR/RD for the dimmer which I assume is orange and red. But I dont know where that connector is. You could take a test light and turn your dimmer on low the hook up the light to a wire on your syereo connector and turn it up it might take a while to find the right wire but the one that gets bright is your winner. It is more of a pain but thats one way. Good luck

SilentxLucidity · **Posted:** Fri Feb 02, 2007 12:19 pm

Here's the wire layout for an '05 without the Infinity stereo system:

The orange wire is your dimmer control. As stated above the dimmer wire will show 0 - 12 Volts going from dim to bright respectively. If you are using a test light, it'll glow brighter as you adjust your dimmer switch (increase). Without the lights on, this wire is sometimes confused as a ground wire... which is funny because your radio will only work when you have your lights off.

Battery PINK (+) RADIO HARNESS
Accesory ORANGE/RED (+) RADIO HARNESS
Ground BLACK (-) RADIO HARNESS
Illumination ORANGE (+) RADIO HARNESS
LF Speaker (+) DARK GREEN
LF Speaker (-) BROWN/RED
RF Speaker (+) VIOLET
RF Speaker (-) DARK BLUE/RED
LR Speaker (+) BROWN/YELLOW
LR Speaker (-) BROWN/LIGHT BLUE
RR Speaker (+) DARK BLUE/WHITE
RR Speaker (-) DARK BLUE/ORANGE
Steering Cntrls NO
Speed Cntrl NO
Radio Security YES

Gris · **Posted:** Fri Feb 02, 2007 1:35 pm

this is a pic I have for the newer radios...

I'd guess pin 3, Orange

gopherbeats · **Posted:** Fri Feb 02, 2007 1:49 pm

Yea.. it should be the orange one.

ibedonc · **Joined:** Mon Feb 12, 2007 2:40 pm **Posts:** 236

What is the PCI BUS ?

thanks

unixxx · **Posted:** Thu Feb 22, 2007 9:37 pm

Jeep Liberty Wikibook wrote:

The "PCI" bus is the central communications bus in the Jeep Liberty. The BCM, PCM, TCM, WCM, EVIC, dash cluster, and audio equipment use it to communicate with each other. The bus is a superset of OBD-II and uses the J1850 VPW communication format. It travels thoughout the entire car and the OBD-II port taps directly into it. A chip from Elm Electronics (ELM327) should allow the user to read/write to the bus via a serial port. While the newer and faster CAN bus is slowely replacing the PCI bus in many Daimler-Chrysler vehicles, the Liberty hasn't made the switch yet.

http://en.wikibooks.org/wiki/Jeep_Liber ... al/PCI_Bus

I've been playing around with it for a while, so let me know if you have any more questions.

ibedonc · **Joined:** Mon Feb 12, 2007 2:40 pm **Posts:** 236

So that must be what the steering wheel buttons use to talk to radio ?

hyedipin · **Joined:** Thu May 11, 2006 10:20 am **Posts:** 1667

ibedonc wrote:

So that must be what the steering wheel buttons use to talk to radio ?

I was just about to ask that!

unixxx · **Posted:** Fri Feb 23, 2007 4:47 pm

Yeah, the steering wheel controls run into the BCM, which then talks to the radio over the PCI bus. It's actually possible to intercept are reproduce these signals, which is one of my projects right now.

hyedipin · **Joined:** Thu May 11, 2006 10:20 am **Posts:** 1667

unixxx wrote:

Yeah, the steering wheel controls run into the BCM, which then talks to the radio over the PCI bus. It's actually possible to intercept are reproduce these signals, which is one of my projects right now.

Please keep us posted on that one.... Or you just buy PAC controller and slap it in between.
I have kenwood HU which accepts wired steering wheel controls through interface, which I have no way of finding (might be out of production, but there is one out there). I do not want to use the IR eye alignment, and I wanted to keep using my steering wheel controls.

CAW-CH1010 Does not list KJ but lists Cherokee (which I assume is KJ since this is EU print)

Thanks
