 Post subject: Arm Rest
PostPosted: Mon Nov 23, 2009 5:09 pm
Offline
KJ / JK Whatever
KJ / JK Whatever
User avatar

Joined: Tue Sep 27, 2005 7:20 pm
Posts: 931
Location: Des Plaines, IL
has anyone opened the back side of the Arm rest?
I was doing some wiring in there yesterday and found out that there is a little square WHITE box with the MOPAR logo on top - does anyone know what this is?
I have left some wiring inside there - most likely no problem with the two heater vents for the back side floor, but i do not know what that thing does - will take a pic later.

_________________


Top
 Profile

 Post subject:
PostPosted: Mon Nov 23, 2009 6:54 pm
Offline
LOST Junkie

Joined: Mon Feb 23, 2009 12:56 am
Posts: 645
Location: Santa Clara, CA
Do you have a 115Volt outlet there?

It might be part of that. I am guessing here..

_________________
2008 Liberty Limited 4X4 Command Trac 2
All stock Auto with 235/60/18


Top
 Profile

 Post subject:
PostPosted: Mon Nov 23, 2009 7:38 pm
Offline
Lifetime Member
Lifetime Member
User avatar

Joined: Thu Apr 09, 2009 1:54 am
Posts: 2079
Location: Bethpage, NY
need pics to verify

_________________
08 Revenge- Rock Lizard (Skink Sliders & Gecko Roof Rails), High Clearance Trimmed Front Bumper, Mopar skids, Riddler Diff Cover, JBA (5.5 Arms, 6" rear Springs, Front Adjust-A-Struts), 32" DuraTracs, Superior 4.56's, Front & Rear ARB Lockers, Fastman Throttle Body, AEM Intake, Hypertech Tune, Custom Ram Air, RunCool Louvers


Top
 Profile

 Post subject:
PostPosted: Tue Nov 24, 2009 10:37 am
Offline
KJ / JK Whatever
KJ / JK Whatever
User avatar

Joined: Tue Sep 27, 2005 7:20 pm
Posts: 931
Location: Des Plaines, IL
Completely forgot to take a picture
No, I did not install anything permanent there - I will not until I'm 100% sure how to do it but it would be nice to have an cig plug in there at the least - it can easily be done.
Specially if you have a small power inverter - like this:
I have just brought the cig extension cord to the back under the center cosole and hid the power inverter inside the backside of the arm rest - that is when I found this little piece I was asking about.
Also, I most likely be extending more cord to have either a 110V plug or at least a cig lighter plug in the cargo area

_________________


Top
 Profile

 Post subject:
PostPosted: Tue Nov 24, 2009 1:33 pm
Offline
LOST Junkie

Joined: Mon Feb 23, 2009 12:56 am
Posts: 645
Location: Santa Clara, CA
warning.. I have used product like and they can blow fuses.
make sure the cirute can handle the load, or have a few back up fuses...

_________________
2008 Liberty Limited 4X4 Command Trac 2
All stock Auto with 235/60/18


Top
 Profile

 Post subject:
PostPosted: Tue Nov 24, 2009 3:38 pm
Offline
LOST Addict
User avatar

Joined: Thu Sep 13, 2007 1:28 am
Posts: 10686
Location: Some where in Colorado
Probably the power inverter..... Also, the "vents" are basically there just for looks........

_________________
2008 KK Liberty Sport NIGHT OPS EDITION + GILLS
OEM & Custom Skids - Factory Tow Package - Rock Lizard Skink Super Sliders
Prototype JBA 4 Inch Lift - JBA UCA's - Flowmaster Super 44 OR - Whacked Resonator
Jet Stage 2 - RL Gecko Basket Rack - Custom Winch Bumper - Recon 10.5K Winch


Top
 Profile

 Post subject:
PostPosted: Tue Nov 24, 2009 9:35 pm
Offline
KJ / JK Whatever
KJ / JK Whatever
User avatar

Joined: Tue Sep 27, 2005 7:20 pm
Posts: 931
Location: Des Plaines, IL
Diggerfreek wrote:
Probably the power inverter..... Also, the "vents" are basically there just for looks........

the vents actually work - there is a bit of heat coming to the 2 sides

_________________


Top
 Profile

 Post subject:
PostPosted: Tue Nov 24, 2009 9:43 pm
Offline
LOST Addict
User avatar

Joined: Thu Sep 13, 2007 1:28 am
Posts: 10686
Location: Some where in Colorado
true.... but it is only radiant heat you are depending on from the transmission tunnel......

_________________
2008 KK Liberty Sport NIGHT OPS EDITION + GILLS
OEM & Custom Skids - Factory Tow Package - Rock Lizard Skink Super Sliders
Prototype JBA 4 Inch Lift - JBA UCA's - Flowmaster Super 44 OR - Whacked Resonator
Jet Stage 2 - RL Gecko Basket Rack - Custom Winch Bumper - Recon 10.5K Winch


Top
 Profile

 Post subject:
PostPosted: Wed Nov 25, 2009 1:24 am
Offline
Taco Killer
User avatar

Joined: Sun Sep 28, 2008 8:26 pm
Posts: 583
Location: Laredo TX
Its not a vent....every KK comes with a ceiling cat:
:shock:

_________________
2009 4x4 Silver Liberty Limited Edition, Premium Group I and II, Skid Plate Group, Exterior Appearance Group by MOPAR, Select Trac II, Sky Slider,uconnect studios,Slush Mats, Hid HEADLAMPS, Interior LED light mod, Scangauge 2, AEM brute force intake, IPOD Integration interface for RER RADIOS, OEM Front end bra.


Top
 Profile

 Post subject:
PostPosted: Wed Nov 25, 2009 8:48 am
Offline
Lifetime Member
Lifetime Member
User avatar

Joined: Tue Mar 31, 2009 4:03 am
Posts: 1503
Location: S.W Washington
I know the Vents in the back of the Nitro center console are functional.
They are connected to the Heater/ A/C system using #6 in this Pic.
BTW this Pic was actually from the 08 Liberty parts list page.
Here.

What is the part # on the white box you are talking about? Do you have a 2 prong outlet on the back of the console? It sounds like a power inverter for the 2 prong outlet.

_________________
07 KA Light Khaki, Manual trany.
2.5" Adjust-A-Strut JBA lift, Euro taillights,
Home made; Front Tilt Hood, Roof Rack, RAM Air, & CAI.
ESP Off Switch
Take a ride on the Trō side!



Top
 Profile

 Post subject:
PostPosted: Wed Nov 25, 2009 9:27 pm
Offline
LOST Addict
User avatar

Joined: Thu Sep 13, 2007 1:28 am
Posts: 10686
Location: Some where in Colorado
:? may be i do have vent there...... been a while since I looked, but I don't remember any
