Hello,

I've got a question : On my car into every bulb there are 2 filaments.

Do you know why?

I know for turn signals there are two filaments. One for the light being constantly on and the other for the flash when the turn signal is on.

Someone could correct me on this but I would imagine you then have two filaments for low beams and high beams

_________________
2012 Jeep Liberty "Arctic" Edition. 2.5" OME lift, 1/4" clevis spacers, 245/75R16 GY Wrangler Duratracs, AtTheHelms steel front bumper, semi gloss black emblems and fuel door, 15% tint all around.

Which bulbs to begin with???
More info needed as to what you are talking about
But can say that many bulbs serve as say running lights and turn signals so need two filaments
Headlights need two for low and high beam etc

_________________
MUDD'S MOTORSPORT'S We do IFS lift installs ,
03 OVERLAND EDITION /Kilby-Skidrow-Mopar-4XGuard skids/ 2.5 inch TOTAL CONTROL JBA coilovers -JBA Arms/MOABS-31 FALKEN WILDPEAK AT3W / 4.10's etc, 04 Kilimanjaro Edition loaded, plus 05 KJ limited

I mean front and also rear bulbs. sorry for my english but i try to explain :

on the rear light you have fog light, turn light, white light to see in the mirror when you... (cant find the word) and stop light.

For stop light i anderstand because its the same for the night light but others...

the taillights have a white reverse light that i believe is only one filament another clear marker for ambers which would have 2 and the brake lights which have two (constant light while headlights are on and brighter for brakes)

I hope this answers your question

_________________
2008 Black Liberty Sport 4X4 - Red and Black wheels and trim - Painted headlight bezels - Magnaflow Exhaust.

ok for the explanation but i dont anderstand why there are also 2 filaments on amber bult on rear lamps and also on white light on rear lamp

The Euro tail lights I have on my KK are the same way. 2 filaments on all the rear bulbs.
When I disassembled the euro "socket-back", I discovered that only 1 of the + connections for the bulb goes to the light. The other one does nothing and is not connected. See the connections on the right side of the socket, there are 4 metal tabs, 2 +(Positive) and 2 - (Negative) connections (running and brake). The next one over only has 2 connections, 1 + and 1 - (turn signal). Next one over also has 2 for the backup lamp, and the left also has 2 for the rear fog.

I believe they did this so you only need to buy one type of bulb to replace any one that is out.

Because of the design of the bulbs only the correct filament will light up no matter which way you install the bulb.

Pos + for bright filament (| |) Pos + for dim filament.
......................................Bulb.................................
....Neg - for dim filament (| |) Neg - for bright filament .

_________________
07 KA Light Khaki, Manual trany.
2.5" Adjust-A-Strut JBA lift, Euro taillights,
Home made; Front Tilt Hood, Roof Rack, RAM Air, & CAI.
ESP Off Switch
Take a ride on the Trō side!
